Tools Part II: Hand Tools For Cutting and Keeping Them Sharp

Making just about anything out of wood means that you are going to need to cut the wood into the correct size and shape for it to be useful. For centuries the only tools carpenters had for cutting and shaping wood were hand saws, wood chisels, and hand planes. And those three hand tools are still essential today. While I use power tools whenever I possibly can (I may be crazy but I’m not stupid) I still use good old fashioned hand versions of those tools all the time.

I’m going to keep this as simple and cheap. You can spend thousands of dollars on hand tools, a lot of them speciality items that you’re probably never going to use or will use only rarely. What you really only need is one saw, three different size chisels, and one or maybe two hand planes. All of the ones I’m going to recommend are reasonably cheap, except for the one hand plane, and you can probably get along nicely without the expensive one. Yes, I have a lot of speciality tools, and I have some tools that are pretty damned pricey, but when it comes down to it the ones I use most often and couldn’t live without are these few.

Saws

Note how the teeth are bent out from the blade. This creates the kerf. Both the bend angle and the grind angle determine if the saw is a rip saw or a cross cut saw.

Saws are a basic tool that have been around since at least the time of the ancient Egyptians. They have evolved a lot over the years but it is basically a metal blade with a series of teeth cut into the edge. The teeth are set at a specific angle and ground in a specific way so they not only cut wood, but also drag the cut wood out of the kerf (the slot left by a saw as it cuts through wood). Without the teeth being set and ground properly, the saw would become jammed in the kerf. The set of the teeth (how far out from the blade of the saw they extend) determines how wide the kerf will be. How the teeth are set and ground also determines if the saw is for ripping or cross cutting. A rip saw is designed to cut with the direction of the grain, while a crosscut saw cuts across the grain. Don’t worry about that, though. You don’t need to have two types of hand saws. I certainly don’t. If I have to rip a board lengthwise I’m going to use my table saw or a circular saw with a guide, not a hand saw. Trying to rip a board down the middle with a hand saw is not something most people want to do. But I will grab a hand saw to whack off five inches of a 2X4 that’s too long rather than go trying to find where I left my circular saw.

So you’re ready to get a handsaw, you run down to the local hardware store, and you grab one of these over there in the photo on the right because, well, it’s a saw, right? A good old fashioned more or less generic Stanley saw. And it will work. Not very well, but it will work. But all things considered, a saw like this will probably work reasonably well for you.

But there is a problem with that saw. The same problem shared by all western style saws. As I said, they don’t work very well.

The problem with western style saws is that they cut on the push stroke. Think about that for a minute. You’re wielding a tool made of a thin, floppy piece of metal, and trying to push it through a piece of wood. What happens? If the saw binds in the kerf or if you move the handle of the saw just a tiny bit left or right while pushing, the saw binds up, comes to an abrupt stop, and the metal blade bends. If you’re lucky that’s all that happens and when you pull back the blade will straighten. If you’re not lucky, you now have a permanently bent saw. This is not a good thing.

Then I discovered Japanese style saws a few years ago and the only thing I use my western style saws for these days is hanging on the wall and serving as a home for spiders. The Japanese saws are simple, elegant, razor sharp, cut on the pull stroke, and generally are so much easier and nicer to use that I haven’t touched one of my western style saws since.

My favorite is from a Japanese maker called Suizan. This one is has a blade a bit less than 10 inches long, has coarse teeth on one side and fine on the other, is razor sharp. It is my all around utility saw here in the shop and the one I use almost all the time. It is a joy to use. It’s not that expensive, either, about $39, and the blade alone can be bought for about $20. Can you get them resharpened when they start to dull? You probably could, but at only $20 for a replacement blade I suspect that having one resharpened would cost more than buying a replacement. Just chuck the old one in recycling and bolt on a new one.

Speciality Saws

Dovetail saw. The only thing I’ll say about it is that you don’t need one, and if you do need one, don’t buy this one because it’s a piece of junk.

I’m going to mention these saws even though you most likely aren’t going to need any of them. At least not unless you’re a really, really high end carpenter turning out very detailed, complex projects. If you’ve done any research at all about woodworking you already know that there are a lot of speciality saws out there like tenon saws, dovetail saws, “gentleman’s” saws, back saws and I don’t know what all else. What about those? Just pretend they don’t exist. Seriously. Oh, they have their place. If, that is, you’re working someplace like Colonial Williamsburg where you have to abandon modern technology and are trying to recreate the past. In the real world, the one you and I live in, no, you don’t need ’em. Do you know when I last cut a dovetail by hand? Maybe twenty years ago just to see if I could do it. If I have to cut dovetails for a joint I use a jig and a router. And as for the other speciality saws? Don’t need ’em. Look, I build full sized wardrobes, cabinets, boxes, chests, make my own hardwood panels for tables, build bookcases, tables, arts and crafts furniture, have made hundreds of mortise and tenon joint and all that fun stuff, and I have never needed one of those speciality hand saws.

Chisels

So, why do you need chisels? See that chair over there on the left? That’s one of mine. There isn’t a single screw or nail in that chair. It’s put together entirely with mortise and tenon joints. A lot of mortise and tenon joints. And while most of them were cut with power tools, the final fitting of the joints was done using wood chisels. Whenever you’re trying to fit bits of wood together you’ll find situations where you need to trim just wee bit off to get something to fit, and often the best tool to use for that is one of these:

Now the set with the wooden handles I have is darn near 20 years old at this point, and back then I paid about $120 or so for those, a pretty hefty chunk of money back then. These are Woodcraft brand and I just looked and they don’t seem to carry these any more. A comparable set I did find over there though was going for… Wait, seriously??? $230??? For a set of six chisels? Well, I suppose with inflation and all that, that’s something I should have expected.

What I’m about to tell you would probably give some woodworkers a stroke, but forget about fancy matched sets, things like “Sheffield steel” and “hand forged” and all that guff. You don’t need a fancy boxed set of over priced chisels. You don’t need six, you could probably get away with two, a one inch and a half inch, and maybe a one-quarter inch. For most people those three are all you’ll probably ever need. Of all the chisels I have, the 1 inch and the 1/2 inch are the ones I use about 95% of the time.

And here’s another thing. One of those chisels up there is not like the others. Way off on the left is that nasty looking one with the black handle. Guess what? The reason it looks nasty is because that one lives on the workbench and gets used for everything. It’s a Stanley brand, looks nasty, has a cheap, dented and stained plastic handle, and I paid a whopping $1 for it at a garage sale. Yeah, a buck. And guess what? It works just as good as the high end Sheffield steel ones to its right. Oh, it doesn’t feel quite as good in my hand, it looks awful, but it holds an edge almost as well as the expensive ones. And because it was so cheap I’m not afraid to whack it with hammers, use it to open paint cans, scrape glue or whatever.

So don’t get all goofy about chisels the way some people do. Just go get yourself two or three cheap Stanley’s off the wall at the local hardware store.

The woodworking “elite” will have a fit about this, but when it comes down to it a chisel is, well, a chisel. What matters isn’t the brand, what the handle is made of or any of that. What matters is if it can be sharpened easily and can hold an edge while being used. Period.

But I’ll be honest, I still love those Woodcraft ones and I think they are much, much better. But whether that is because they really are better, or I just think they are, well, I’m not really sure.

Sidenote: I talk about the Stanley brand hand tools quite a bit in this because it is a brand just about anyone who has ever been in a hardware store will recognize, not because I have stock in the company or something like that. I know a lot of people badmouth Stanley hand tools and I’m not sure why. They’re cheap, usually of decent quality, and generally better than the more generic brands that seem to pop up and then vanish almost overnight every few months.

Planes

The other cutting hand tool I want to talk about is the handplane.

Planes get complicated real fast because there are dozens of different types of special purpose planes out there. But you really don’t need to worry about any them. While there are some really neat speciality planes, generally when it comes to those speciality needs you’re going to resort to using power tools like a router, shaper, jointer or planer. But the two most basic types of hand planes can be very useful.

A hand plane is, well, basically it’s a wood chisel held in a special frame. The frame holds the plane iron (the cutting bit) it at a specific height and angle so it doesn’t cut too deep and helps to direct shavings up away from the throat of the plane and out of the way of the cut. It lets you smooth off high spots on a piece of wood, trim the edges of a board, trim the edge of a door that doesn’t fit, shave off sharp corners, that kind of thing.

The one on the bottom is my favorite. That is a Stanley block plane (sheesh, there’s Stanley again). Block planes are a bit different from a standard bench plane (that’s the one with the wooden handles in that photo). The blade is set at a lower angle, with the bevel up, and it is designed to cut end grain easily and do light touch up work, take off sharp edges, and work across the grain instead of with the grain. It’s small enough to use with one hand, fairly lightweight and easy to use. This one lives full time on my workbench and it gets used a lot. I use it for cleaning up tenons, knocking off sharp edges and things like that.

They’re handy and reasonably cheap. Dear lord, don’t buy into the hype and pay a hundred bucks or more for one of the fancy ones block planes!. The Stanley works quite nicely, thank you very much, and you can get one for about $30 off Amazon. Yes, you’ll need to do some tinkering with it to get it to work really well, although out of the box is generally isn’t horrible. You’ll definitely need to sharpen the blade and perhaps flatten it. And you may need to flatten the sole of the plane. But that’s easy enough to do with some wet/dry sand paper glued to a sheet of glass. And there’s no need to get obsessive about it and get out your micrometers and all that. Close is good enough for a block plane.

If you do get a plane, I recommend you go out on the internet and look at a short 7 minute video at Fine Woodworking’s website about how to properly “tune up” a plane. (https://www.finewoodworking.com/2013/09/26/handplane-tune-up-tips) Most hand planes will need to be checked over and have some work done to them before they work really well. It isn’t that hard to do, doesn’t take long, and that video goes through the basics pretty well. If you know what you’re doing you can take even take a not very good hand plane and make it work at least reasonably well.

The other plane up there is my Wood River #4 1/2 bench plane.

So, what’s a bench plane do, and do you need one? Basically this is what you’d call a smoothing plane. It’s used to smooth the surface of wood, take down high spots, smooth rough areas and things like that. The #4 is the most common size, usually about 9″ long and with a blade that’s about 2″ wide. I find the #4 a good, all around size. But I prefer the 4 1/2 personally.

So what’s with the 1/2 bit? The 4 1/2 is longer, about 10″, the blade is a bit wider, and it is considerably heavier. I work with mostly hardwoods like white oak and ash, and since I build furniture I work with some lengthy pieces of wood. The 4 1/2 is heavier, meaning it’s easier to keep enough downforce on it to keep a cut going even in hardwood. It’s slightly wider so it covers more territory. And the way I have this one set up and tuned up I have virtually zero tearout. It is smooth and slick and cuts through hardwood like butter, peeling off shavings so thin you can almost read through them. I love this plane. I used this plane to smooth down a white ash table top that was two and a half feet wide and almost four feet long. If it can handle that, it can handle anything.

But do you need one? While they can be nice to have, probably not. Not for a newcomer to woodworking. Nor is something like this an impulse purchase because this is the most expensive hand tool in the whole bunch. The Wood River up there currently is selling for about $200. Granted the Wood River is a high quality hand plane. There are more expensive ones on the market but I did a lot of research before buying this one and the Wood River line of hand planes is just plain good across the board. (oh, wait, that was a pun, wasn’t it – plane, plain. Feel free to wince if you like.)

What about the cheap ones? You can pick up generic bench planes for not much more than that Stanley block plane. But almost all of those aren’t worth the effort it would take to recycle ’em. I have a few of those cheap models, and no matter what I do to them to try to properly tune them up, they’re so badly made with such poor tolerances and poor materials they’re pretty much hopeless.

What about used planes? Well, good luck in finding one at a decent price. Old hand planes have become collectors items, and collectors have driven the price of old planes through the roof. If you do find one chances are good it’s been used hard and will be in bad condition and won’t be good for anything except as a display piece.

In my opinion you probably won’t need a bench plane unless you start to get into building high end stuff. For most of us, all you really need is that $30 block plane.

Sharpening Stuff

Sooner rather than later you are going to need to sharpen this stuff. Chisels get dull, plane irons get dull, saws get dull, and when that happens they don’t work well and can even be dangerous. A mentor of mine once said that more people get hurt by dull tools than sharp ones, and he had a very valid point. Unfortunately nothing seems to generate more hot air, bluster and nonsense than the topic of sharpening. Entire books have been written about sharpening, there are hundreds of hours of video floating around out there, and to be frank, a lot of it is pure nonsense. Some people get ridiculously obsessive about sharpening, often to the point where I don’t see how they ever actually get any work done because they’re spending all their time trying to get the perfect edge on their tools rather than actually doing any work.

Saw Sharpening

I don’t recommend sharpening saws yourself. It requires special tools and skills and generally isn’t worth the effort. Use a sharpening service. Or better yet start using the Japanese style saws like the Suizan up there and when it goes dull just recycle the blade and buy a new one. As I said before, $20 for a replacement blade is probably going to be cheaper than trying to get it resharpened. And the blades last a long, long time.

Chisel and Plane Sharpening

This is something you can do for yourself, and you’ll have to do it because chisels and plane irons get dull pretty quickly depending on what you’re doing with them.

There is a lot of silly stuff floating around on the internet about sharpening, and most of it isn’t worth bothering to read or listen to. I don’t think I’ve ever seen a subject where people get more weird and obsessive than sharpening. This is going to irritate a lot of people, I imagine, but when you find these guys talking about getting mirror polish on the bevels, sharp enough to shave with, and all that guff, it’s just that, guff. It doesn’t matter! The goal isn’t producing a chisel or plane iron that you can shave with, it’s creating an edge sharp enough to cut wood and staying sharp during a reasonable amount of use. I’ve seen Youtube videos of guys spending twenty bloody minutes to get the perfect edge on a chisel. But guess what? The very first time they actually use that chisel the edge is already starting to dull and it doesn’t cut wood any better than my chisels do. And it takes me maybe 30 seconds to sharpen mine.

Don’t get me wrong. Sharpening your tools is incredibly important, and it’s something I have to do so often that I have a workbench setup exclusively for that purpose. And you’ll notice that there isn’t a single leather strop, expensive sharpening stone, exotic honing oils or or diamond hones or any of that other stuff sitting around there. Just two power grinders, the Rikon with the white abrasive wheels for my lathe tools, and the Work Sharp sharpening wheel I use for chisels and plane irons.

Let’s look at a really bad drawing of the parts of a chisel.

Thought I was kidding when I said it was a really bad drawing, didn’t you?

When sharpening a chisel (or a plane iron) there are three things we’re concerned with; the angel of the bevel, the cutting edge and, believe it or not, the back side of the chisel. You’d think that the only important thing when sharpening a chisel is getting that cutting edge sharp. But that’s only one third of the whole process. All three of those determine how well the chisel will cut wood. Sounds complicated but it takes me a half minute or less to do it.

Here’s a short video of me down below sharpening my $1 garage sale special Stanley chisel, and doing it in less than half a minute. How? I cheat of course. I use a machine. In this case it’s a Work Sharp sharpening system. And yes, it works just as easy and fast as it shows in the video once you get it set up. I admit it isn’t cheap. It goes for about $200 over on Amazon. But the darn thing just works. I don’t know how much time and effort this thing has saved me in the years I’ve owned it. I’ve had this one for, good grief, must be ten years or so now. It is one of the very few sharpening tools I own that actually lives up to its advertising.

Let’s see if this video thingie actually works and take a look at me actually sharpening a chisel, in this case my beat up old $1 garage sale Stanley.

dear lord that shop is a mess!

Egads, looks like it did upload the video. Okay, let’s go through this.

I blackened the backside of the chisel and the bevel to make it easier to see what actually happens. First I put the back of the chisel flat down on the sharpening wheel and hold it in place to make sure the back of the chisel is perfectly flat. Once I do that, I put it in the guide underneath and slide it up onto the underside of the wheel, which also has an abrasive on it. The guide holds it at the correct angle for the bevel. Then when it was finished sharpening I got a piece of scrap oak and sliced some end grain to see how sharp it was. Which was pretty darn sharp. It doesn’t slice through end grain like a hot knife through butter, but it’s pretty darned close to that. You couldn’t shave with that chisel, but I don’t want to shave with it, I just want it to cut wood, and it does quite nicely, thank you. And it took – what? Less than 20 seconds to sharpen it?

But, GF, you say, I don’t want to drop $200 just to sharpen a chisel. Good for you. I don’t blame you at all, and you don’t have to. You can do it by hand with a piece of glass, some wet/dry sandpaper and one of these.

As the label says, that’s a honing guide made by Veritas. It, along with the gadget to help you set the correct bevel angle, will set you back about $70, or a bit less if you shop around. When set up properly it will hold your chisel or plane iron at the proper angle. Then you get out a piece of glass, stick some wet/dry sandpaper to it, and use the guide to hold the chisel properly while you move it back and forth across the sandpaper. You start with maybe, oh, 240 grit paper, and work your way up to 1,000 grit. That should give you and edge that’s more than sharp enough for general woodworking.

It works reasonably well, and I sharpened chisels like this for a long time before I got the Work Sharp rig.

That’s it for this time. In part 3 I’ll look at tools where the prices do get pretty high pretty fast, power tools.

Tools Part I (Yes he’s bored again and you’re going to suffer for it)

Let’s talk about tools for a while. I had a few questions from people interested in (you can ask questions in the comments or email me at old.grouchyfarmer@gmail.com) about woodworking tools, so I thought this was a good time (OMG I’m sooo bored…) to talk about what you need, what the prices are like, things you should look for, things you should avoid, etc.

(Disclaimer: I should point out that I do not get free stuff from manufacturers or vendors, I don’t accept advertising, I don’t get paid for anything I publish here. Every tool, piece of equipment or other supplies that I mention in these posts was purchased by myself, with my own money. My comments are based totally on my own experiences with any products I mention. I only comment about products I have actually used myself. )

When talking about tools things get complicated because it is such a general category that it can include everything from the tweezers you use to pull slivers out of your hand all the way up to massive power tools. To complicate things even more, there are tools you need just to keep your other tools operating properly. I’m going to try to keep this as simple as I can, though.

And I should point out that tools can get expensive real fast. But generally speaking you don’t need to spend huge amounts of money. Most of those super expensive tools are basically intended for people who have more money than brains. But I’ll get into that as I talk about more specific types of tools.

So, let’s get on with this, then.

First Of All Protect Your Ass Yourself

I’m not going to sugarcoat this. Woodworking is dangerous. But then so is, well, eating breakfast, as far as that goes. Do you have any idea how many people end up in the ER from breakfast related injuries, or even killed? So much for that “most important meal of the day” BS. (That “most important meal” nonsense was started by a cereal company, by the way.)

So the first thing I want to talk about is safety gear to keep you from ending up in the emergency room.

First of all there is eye/face protection. You’re working with sharp tools, power tools that spin at hundreds or even thousands of RPM, wood that shatters and splinters, and while an eye patch may look good on a pirate or Commander Fury, in real life it isn’t much fun.

Those safety glasses you see people wearing on This Old House and home improvement shows are better than nothing, but they’re entirely inadequate for anything except a direct frontal impact. They have minimal side shielding, fit loosely, and generally do little to protect your eyes from stuff coming in from the sides. And stuff will come in from the sides. I guarantee it. What you need is something like this:

They give protection all the way around, seal tight against the skin, are not only impact resistant but dust resistant as well. Uncomfortable to wear? Yep. But would you rather be uncomfortable for a few hours or lose an eye? Yeah, thought so. They’re also cheap. You can usually get decent quality safety goggles for well under $10.

Now I do wear those goggles up there sometimes, but they don’t protect the entire face so what I personally prefer, is this:

This is a full face shield from Honeywell Safety Products. This is generally what I wear. It can be easily worn over prescription glasses, protects the entire face, not just the eyes, and is far more comfortable to wear than the goggles are. And it’s easy to wear it over the top of most respirators, although it’s a tight fit over the top of a cartridge respirator. And it’s not real expensive. You’re going to pay under $40 for one like this. You can get better ones than this, at a higher price, of course. Some even come with air filtration systems, but those are a bit awkward to wear and damn they’re expensive.

And speaking of respirators…

Protect Your Lungs

Working with wood generates dust, a lot of dust. Just about everything you do with wood makes dust. Whether it’s sanding or sawing or wood turning, it is going to make dust. And while a lot of people seem to be under the impression wood dust is generally harmless, it isn’t.

Now I know that “the state of California has determined that (insert product of your choice here) can cause cancer” warnings have turned into pretty much a joke, but in this case they’re right. Long term exposure to wood dust does seem to be linked to an increased risk of cancer. It is also linked to asthma attacks, chronic lung impairment, life threatening allergic reactions and other nasty stuff. To make things even more interesting, some types of wood are literally toxic.

Now you can have the best dust extraction system in the world (and let’s face it, most of us don’t have any kind of dust extraction system except maybe a shop vac) but you’re still going to get ultrafine particles of wood floating in the air and ending up in your lungs unless you wear a respirator of some type.

Just about every hardware store carries (or did carry before the pandemic hit) paper masks laughingly called “respirators” or more generically, “dust masks”. Most of those are, frankly, just about worthless. They do little or nothing to remove the very fine particles of dust floating around in the air. The “gold standard” when it comes to paper type respirators is, of course, one of these:

That’s a N95 respirator, and that’s what I used to wear before they became unavailable because of the pandemic. Yes they were expensive. But no where near as expensive as having your lungs ruined. Now you can’t find them anywhere, and if you can find them for sale chances are good they’re counterfeits and/or insanely expensive. (I would really, really like to know why, some 8 months into this pandemic, protective equipment is still in such short supply that it still needs to be rationed.)

What I wear is this:

That’s a respirator from MSA with replaceable filter cartridges. It provides better protection than even an N95 mask, and, believe it or not, these masks and cartridges are still generally available. And they aren’t that expensive, either. A quick peek at Amazon tells me the masks, without cartridges, are going for about $15. The cartridge filters are not cheap but not as bad as you might think. Depending on the type of cartridge they’re going for under $20 or so for a pair. And the cartridges last for much, much longer than the typical N95 paper mask does.

Is it comfortable to wear? Not really, but at the same time it isn’t horrible to wear, either. And you do get used to it and hardly even know you’re wearing it after a while. I’m used to it and it’s nowhere near as difficult to wear as some of the safety gear I had to wear for enclosed spaces training or even when painting cars. To be honest I hardly know I have the thing on once I have it in place. (Needless to say I have no respect at all for the little cry babies who whine about ‘but it’s so hot and uncomfortable’ when they have to wear a light weight surgical mask in a store. I’d like to see what they’d think of having to wear full air gear including 100+ lb. air tanks, full face mask and a protective suit.)

Whichever respirator you wear, you have to wear it the right way. It isn’t going to do you any good at all if you don’t have a good seal against bare skin. (As one of my instructors once said, if you can smell anything, you’re already dead. He had a rather warped sense of humor.)

Speaking of surgical masks, will one of those protect your lungs? Those might be better than nothing but they aren’t very good for this kind of thing.

Ewwww! It’s Sticky!

Let’s talk about glue. A large part of woodworking is attaching one piece of wood to another. And often the best way of doing it is to glue those suckers together.

Now there are dozens of different brands of wood glue out there, and I’ve tried pretty much all of them over the last twenty or so years. To be honest, there’s really not much difference between the name brands as far as performance goes. But the one I’ve used almost exclusively for years now is Titebond. The company makes different types of glues, but my favorite is Titebond III Ultimate wood glue. The stuff just plain works if you follow the instructions on the bottle. I’ve never had a glue joint fail as long as I used reasonable care and followed the instructions. It’s easy to use, has little or no odor with no toxic fumes (unlike CA adhesives), is reasonably easy to clean up and it just works. Best of all it’s reasonably inexpensive.

Clamps are your friends.

The drawback to most wood glues, including Titebond, is that the wood needs to be clamped for an extended period of time. Hours. Generally I’ll leave it in the clamps for at least twelve hours before doing anything that would put strain on the glued joint

That means, of course, that you need clamps. Lots and lots of clamps. Someone once told me you can’t have too many clamps and for me, at least, that seems to be true. Don’t get too obsessive about clamps. Some people get a bit weird when it comes to clamps. Most of us don’t need anything fancy. For most of us a clamp is a clamp is a clamp, and as long as it’s fairly easy to adjust and doesn’t bend when it’s under pressure, it’s going to be good enough. I have everything from cheap hardware store junk all the way up to the pricey Jorgenson brand name clamps, but in the long run they all do the same thing, clamp stuff together. I do prefer the ones that have the squeeze handles for clamping instead of the screw type. Those are much easier to work with. But in the long run, they’re all still clamps.

What About CA (cyanoacrylate) Adhesives?

CA glues, or “super glue” or “instant glue” or whatever you want to call them, are the ones that bond virtually instantly (well, actually they really don’t bond instantly). And it is really tempting to try using them instead of having to clamp up joints for hours using normal wood glue, isn’t it? Just slap on some CA glue, stick the wood together, and bang, it’s done.

But CA glues have some issues as they say.

Now I’ve experimented extensively with CA glues over the last few years, especially after watching Youtube videos of guys slapping together bits and pieces of wood with one type of CA glue or another and then chucking it up on a lathe and whacking away at it with a bloody great roughing gouge while spinning it at about a gazillion RPM. To say that doing something like that would make me a wee bit nervous is an understatement. While I’ve never had a Titebond wood glue joint fail on me, I have had multiple CA glue joints fail. Enough so that I don’t trust the stuff to be able to handle any significant sheer forces. So my experience with CA adhesives in general is that while they have their place, they generally don’t work well with wood.

But that being said, I have had good luck with Starbond CA glues. I use it with wood turning projects for things like stabilizing cracks in bowl blanks, reinforcing weak wood and things like that. It works amazingly well for that. Especially the very thin consistency stuff. Saturate the bad wood or crack with the adhesive, give it a shot of accelerator to cure the glue, and away I go without having to worry about the crack causing a piece to shatter or a bit of punky wood wrecking an otherwise nice bowl blank.

There are three problems, though, that are shared by virtually all CA type adhesives.

First of all the stuff is expensive. That little 2 oz bottle of Starbond black medium up there costs almost as much as a whole quart of Titebond III. A quart of Titebond III is about $19. That 2 oz bottle of Starbond Black in the photo up there sells for $15. And you really need the accelerator as well, which will set you back another $14.50. So while Starbond works really well, it can be prohibitively expensive if you use large quantities of the stuff.

The second problem is it is still a CA based adhesive, so that means it gives off some very nasty fumes, as does the accelerator. If you’re using more than a few drops of the stuff it is recommended you do so only with very good ventilation or wearing a respirator.

The third problem is that it has virtually zero open time. Literally zero open time if used with an accelerator. What’s open time? That’s the amount of time you have before the adhesive begins to cure and you can no longer move the two pieces of wood to position them. With a glue like Titebond, you have many minutes before the glue begins to setup so you can move the pieces around to get them positioned properly before you put on the clamps. But with CA glues like Starbond, there is literally zero open time, especially if you’re using an accelerator. You apply the adhesive to one piece of wood, apply the accelerator to the other, slap them together and they are immediately bonded. You’d better make darn sure that you have those pieces positioned properly the moment you put them together, because that’s it. Once they touch, they’re bonded.

I’ve bored you long enough. Part II (if I ever get around to writing it) will look at hand tools for cutting wood; things like saws, wood chisels and lathe tools, an how to keep them sharp.
